4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding

顧客の検討
非常に本当にありがとう。私は私達が油圧バット融合機械溶接ビジネスを将来作ることを望む。

—— Rusi氏

ありがとうの友人。それはあなたに対処する喜びである。

—— ウォルター氏

参照をありがとう、私は深刻で、評判が良い会社であることを見る。

—— Dantas氏

オンラインです

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding
4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding

大画像 :  4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding

商品の詳細:
起源の場所: 中国
ブランド名: MM-TECH
証明: CE
モデル番号: SWT-UME
お支払配送条件:
最小注文数量: 1セット
価格: US$2160-2200/set
パッケージの詳細: アルミ箱
受渡し時間: 5-8営業日
支払条件: T/T,ウェスタン・ユニオン
供給の能力: 1000セット/週
詳細製品概要
適用する: バナー,テント,テラパイン,その他の厚い素材 溶接方法: テープ溶接
モデル: SWT-MAT2 電圧: 230V
パワー: 4200w 溶接速度: 1.0〜10.0m/min
熱気温: 50〜620°C 溶接シーム: 40/50/80mm
純重量: 24Kg
ハイライト:

Tpo Tarpaulin Welding Machine

,

40MM Tape Welding Machine

,

4200W Tape Welding Machine



4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 0

Product description:



Mobile and desktop hot-air welding machines meet the different process requirements such as overlap welding, hem welding, rope welding, tape welding and so on. The operation is convenient, simple and efficient, which provides customer with the best user's experience. Provide practical and high-quality equipment and application solutions for the splicing and production of advertising printing, fast soft doors, awnings, tents, inflatable castles, plastic products, etc.



SWT-MAT2 hot air welding machine fittings made of PVC can be operated in any complex work condition. It made of lightweight and high strength material; simple structure, small and delicate, user friendly.



Application Banner,tent,tarpaulin and other thick materials
Model SWT-MAT2
Welding way Tape welding
Voltage 230V
Power 4200W
Welding speed  1.0-10.0m/min
Heating temperature 50-620℃ adjustable
Welding seam 40/50/80mm
Net weight  24kg
Certificates  CE



Hot Air Welder Operation Guide:



1. Unplug the tools before opening it to avoid of being hurt by exposed wires or component inside the machine with

power



2. Incorrect use of it can cause fire and explosion hazard because of high temperature, especially near combustible

materials and explosive gases.

3. Don’t touch heater tube and nozzle when they are hot. They may cause burns. Don’t point hot air flow in the
direction of people or animals.

4. The voltage rating stated on the welder must correspond to line/mains voltage (220V).
The drop cable / wire with protective earthed conductors can only be used.

5. To ensure operator safety and reliable operation of equipment, the power supply must be installed power supply
and leakage protection at the construction site.

6. It must be running at the correct use of manipulation of the operator, or they may cause a fire or explosion caused
by high temperature.


Products Advantage:



1.CONTROL SYSTEM

Intelligent control system,easy to be operated.

2.ROLLERS

Advanced belt combined with pressure rollers system keeps.

3.POSITION

Accurate positioning system makes sure welding towards straightly.
4.HEATING

40mm/50mm/80mm welding nozzle available.



Appication:

Heavy-duty tarpaulin production (truck covers, tents).
Inflatable products (boats, airbags, PVC pools).
Industrial fabrics (conveyor belts, tank liners).
Advertising materials (billboards, banners).

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 1

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 2

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 3

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 4

4200W 40MM Tpo SWT-MAT2 Tarpaulin Welding Machine Tape Welding 5



FAQ:

1. PAYMENT TERMS
We accept 30% TT deposit and 70% balance payment against photo before delivery or 100% TT in advance.

2. LEAD TIME
Usually, we have plenty of stock for V355 and below, and keep max. 3units for V450 and V630. As to V800 and above, we'll arrange production according to the actual orders.

3. WARRANTY
2 YEARS. During the warranty period, MM-Tech authorized dealer and MM-Tech will totally cover the responsibility to fix the machine; Claim parts usually could be couriered to clients within 3days since receiveing the claim. Express fee will be borned by MM-Tech.

4. CAN YOU DO CUSTOMIZED DESIGN
YES.
MM-Tech has its own design and technical team that can undertake OEM and ODM, but there are quantity requirements, please contact our sales consultant for more information, thank you.

5. CAN YOU PROVIDE TRAINING CLASS ?
1. Customers are welcome to come to our factory for 1-2 weeks of training, in addition to air tickets and hotels, MM-Tech can afford meals and local transportation costs.
2. We can also arrange for technical personnel to fly to the customer's local to do on-site training, for a period of 1-2 weeks,customers bear air tickets, hotels, catering, as well as technical training fees, please contact our sales consultant for details.
3.MM-Tech offers online training in English and Spanish, which requires an appointment in advance.

6. HOW COULD BE YOUR DISTRIBUTOR AT LOCAL?
MM-Tech welcomes customers from all over the world to negotiate agency business, but for agents, we have specific requirements, details please contact our sales consultant, thank you!
